Display
Brightness (ANSI lumens) 5100
Resolution 4K UHD (3840×2160)
Native Aspect Ratio 16:9
Contrast Ratio (FOFO) 3,000,000:1
Display Color 30-bit (1.07 billion colors)
Light Source Laser
Light Source Life a. Normal 20000 hrs
Optical Throw Ratio 0.81 ~0.89
Zoom Ratio 1.1x
LensF/# =1.83 ~ 1.86 f= 8.6 ~ 9.4
Projection Offset (Full-Height) 0%
Keystone Adjustment 3D, Vertical ± 40 degrees; Horizontal ± 40 degrees; Rotation ± 40 degrees
Lens Shift Vertical -60%~ +60%
Lens Shift Horizontal -23%~ +23%
Picture Rec. 709 Coverage 92%
Compatibility Input Lag 33.4 ms (1080P 60Hz)
Resolution Support VGA (640 x 480) to 4K UHD (3840 x 2160)
Horizontal Frequency 15K~135KHz
Vertical Scan Rate 23~240Hz
I/O Interface HDMI in (x2), HDMI-1 (2.0b/HDCP2.2), HDMI-2 (2.0b/HDCP2.2)
Display Port (x1) LAN (RJ45) (x1) HDBaseT (RJ45)(x1), Video/Audio 3D Sync in(x1), VESA 3D Sync out (x1), VESA
USB Type A (x1), USB Type A-1 (2.0/Power Supply2.0A) RS232 in (DB-9pin) (x1)
Wired Remote in (3.5mm Mini Jack) (x1) Wired Remote out (3.5mm Mini Jack) (x1) DC 12V Trigger (3.5mm Jack) (x1)
Audio Speaker (x1), 10W Audio out (3.5mm Mini Jack) (x1)
HDMI Audio Return Yes, eARC, Dolby Atmos S/PDIF Multi-Channel, RAW Environment
Operating Temperature 0~40℃
Power Supply AC 100 to 240 V, 50/60 Hz
Typical Power Consumption (110V) 440W
Stand-by Power Consumption <0.5W
Network Stand-by Power Consumption <2W
Acoustic Noise (Typ./Eco.)(dB) 40/33
Accessories Remote Control w/ Battery RCA011 Power Cord (by region) x1 (1.8M)
HDMI cable 1.8m 3D Glasses DGD5, (Optional)
Installation Guide 1 (8L) Warranty Card (by region) Yes
Universal Ceiling Mount CM00G3, (Optional)
Weight Dimensions (WxHxD) (mm) 416x166x351 Net Weight (kg) 7
Projection System
