Product Information
Product Name
NEC PA1705UL
Product Group
Professional Advanced LCD Laser Installation Projector
Order Code
60005972 (W), 60005932 (B)
Projection Technology
3LCD Technology
Native Resolution
1920 x 1200 (WUXGA)
Aspect Ratio
16:10
Contrast Ratio 1
3000000:1
Brightness 1
16000 Lm / 17000 Lm Center
Lamp
Laser Light Source
Light Source Life [hrs]
20000 2
Lens
6 motorized lens options
Lense Adjustment
Motorized
Lens shift
Up to H:±25, V:+65,-65
Keystone correction
+/- 40° manual horizontal / +/- 30° manual vertical
Projection Factor
depending on lens selection (std. option NP54ZL at 1.25-2.01:1)
Projection Distance [m]
0.68 – 80.77
Screen Size (diagonal) [cm] / [inch]
Maximum: 1,270 / 500″; Minimum: 152 / 60″
Zoom
Motorized
Focus Adjustment
Motorized
Supported Resolutions
1080i/50/60;1080p/24/25/30/50/60;1920×1200 (WUXGA)
640×480 (VGA);2048 x 1080 (2k);
2560 x 1600 (WQXGA);4096 x 2160 (4k);720p/50;720p/60
Frequency
Horizontal: analog: 0-0 kHz, digital: 15/24-153 kHz; Vertical: 24 – 120 Hz
Connectivity
Digital
Input: 1 x 3G-SDI; 1 x HDBaseT; 2 x HDMI™ supporting HDCP 2.2
Output: 1 x HDBaseT supporting HDCP 2.2
Output: 1 x HDBaseT supporting HDCP 2.2
Audio
Input: 1 x HDBaseT audio support; 2 x HDMI audio support
Output: 1 x 3.5 mm Stereo Mini Jack (variable)
Output: 1 x 3.5 mm Stereo Mini Jack (variable)
Control
Input: 1 x 3.5 mm Stereo Mini Jack (Wired Remote); 1 x D-Sub 9 pin (RS-232), Ethernet
LAN
1 x RJ45
USB
1 x Type A (USB 2.0 high speed)
Remote Control
Audio Control; Digital Zoom; Geometric Correction; ID Select; ID set;
Power (On-OFF); Select (up, down, left, right); Shutter function; Source Select;
Test Picture; Zoom/Focus and Lens Shift Control
Electrical
Power Supply
100-240 V AC; 50 – 60 Hz
Power Consumption [W]
995 Normal / 825 Silent Mode / 0,5 Network Stand-by / 2,0 Stand-by
Mechanical
Dimensions (W x H x D) [mm]
599 x 238 x 490 (without lens and feet)
Weight [kg]
28.7
Fan Noise [dB (A)]
43 / 37 (Normal / Silent)
Colour Versions
Black; White
